CLIP

Weights: the pretrained weights for the CLIP model are hosted on the kerasformers clip release tag, and download automatically the first time you call from_weights(...).

CLIP (Contrastive Language-Image Pre-training) is a vision + text dual-encoder trained on hundreds of millions of (image, caption) pairs with a contrastive loss. The vision side is a ViT; the text side is a small transformer with causal masking. Both encoders project to a shared embedding space, and a learnable temperature scales the cosine-similarity logits.

CLIP's similarity-matrix output makes it useful for many downstream tasks: zero-shot classification, image-text retrieval, image-image similarity, embedding extraction for diffusion models or VLMs, and (with a supervised head) standard image classification.

Paper: Learning Transferable Visual Models From Natural Language Supervision

API

CLIPModel

CLIPModel(embed_dim=512, image_size=224, vision_num_layers=12, vision_hidden_dim=768,
          vision_patch_size=32, max_seq_len=77, vocab_size=49408, text_hidden_dim=512,
          text_num_heads=8, text_num_layers=12, vision_mlp_ratio=4.0,
          text_mlp_ratio=4.0, hidden_act="quick_gelu", layer_norm_eps=1e-5,
          input_tensor=None, name="CLIPModel")

The dual encoder itself, and the base the other two classes build on. Returns projected but un-normalized embeddings, for retrieval, image-image similarity, or as frozen features.

Parameters

• embed_dim (int, optional, defaults to 512): shared embedding dimension, the projection_dim of the HF config.
• image_size (int or tuple, optional, defaults to 224): input image spec. An int builds an N x N x 3 input, a 2-tuple (H, W) assumes 3 channels, and a 3-tuple follows the active keras.config.image_data_format().
• vision_num_layers (int, optional, defaults to 12): ViT encoder depth.
• vision_hidden_dim (int, optional, defaults to 768): ViT hidden dimension.
• vision_patch_size (int, optional, defaults to 32): ViT patch size.
• max_seq_len (int, optional, defaults to 77): text input length.
• vocab_size (int, optional, defaults to 49408): tokenizer vocabulary size.
• text_hidden_dim (int, optional, defaults to 512): text encoder hidden dimension.
• text_num_heads (int, optional, defaults to 8): text encoder attention heads.
• text_num_layers (int, optional, defaults to 12): text encoder depth.
• vision_mlp_ratio (float, optional, defaults to 4.0): MLP expansion ratio in the vision blocks.
• text_mlp_ratio (float, optional, defaults to 4.0): MLP expansion ratio in the text blocks.
• hidden_act (str, optional, defaults to "quick_gelu"): MLP activation. Use "quick_gelu" for canonical OpenAI CLIP, "gelu" or "gelu_new" for LAION and community variants.
• layer_norm_eps (float, optional, defaults to 1e-5): epsilon for every LayerNorm.
• input_tensor (dict, optional): pre-existing input tensors to build on.
• name (str, optional, defaults to "CLIPModel"): model name.

Returns a dict:

• image_embeddings ((B_img, embed_dim)): projected, un-normalized image embeddings.
• text_embeddings ((B_txt, embed_dim)): projected, un-normalized text embeddings.

CLIPZeroShotClassify

CLIPZeroShotClassify(embed_dim=512, image_size=224, vision_num_layers=12,
                     vision_hidden_dim=768, vision_patch_size=32, max_seq_len=77,
                     vocab_size=49408, text_hidden_dim=512, text_num_heads=8,
                     text_num_layers=12, vision_mlp_ratio=4.0, text_mlp_ratio=4.0,
                     hidden_act="quick_gelu", layer_norm_eps=1e-5,
                     input_tensor=None, name="CLIPZeroShotClassify")

CLIPModel plus the contrastive head: L2-normalize both sides, then scale the cosine similarities by logit_scale. This is the class for zero-shot classification.

Parameters are identical to CLIPModel, except name defaults to "CLIPZeroShotClassify".

Returns a dict:

• image_logits ((B_img, B_txt)): scaled cosine similarity, image i against text j.
• text_logits ((B_txt, B_img)): its transpose.

CLIPImageClassify

CLIPImageClassify(num_classes=1000, image_size=224, vision_num_layers=12,
                  vision_hidden_dim=768, vision_patch_size=16, vision_mlp_ratio=4.0,
                  hidden_act="quick_gelu", layer_norm_eps=1e-5, input_tensor=None,
                  name="CLIPImageClassify")

The vision tower only (mean-pooled patches, no text side) with a linear head. Needs a checkpoint whose head was actually trained, which no release variant has. See Supervised Image Classification.

Parameters

• num_classes (int, optional, defaults to 1000): number of output classes.
• image_size (int or tuple, optional, defaults to 224): as in CLIPModel.
• vision_num_layers (int, optional, defaults to 12): ViT encoder depth.
• vision_hidden_dim (int, optional, defaults to 768): ViT hidden dimension.
• vision_patch_size (int, optional, defaults to 16): ViT patch size.
• vision_mlp_ratio (float, optional, defaults to 4.0): MLP expansion ratio in the vision blocks.
• hidden_act (str, optional, defaults to "quick_gelu"): MLP activation.
• layer_norm_eps (float, optional, defaults to 1e-5): epsilon for every LayerNorm.
• input_tensor (dict, optional): pre-existing input tensors to build on.
• name (str, optional, defaults to "CLIPImageClassify"): model name.

Returns a tensor of shape (B, num_classes): raw class logits.

The distinction that catches people: CLIPModel gives you embeddings, CLIPZeroShotClassify gives you logits. Asking CLIPModel for output["image_logits"] raises KeyError.

CLIPVisionModel

CLIPVisionModel(image_size=224, vision_num_layers=12, vision_hidden_dim=768,
                vision_patch_size=32, vision_mlp_ratio=4.0, hidden_act="quick_gelu",
                layer_norm_eps=1e-5, input_tensor=None, name="CLIPVisionModel")

The vision tower on its own: patch embedding plus the transformer stack, ending at the post-encoder LayerNorm. No text tower and no visual_projection, so use it when you only want image features.

Parameters

• image_size (int or tuple, optional, defaults to 224): input image spec, as in CLIPModel.
• vision_num_layers (int, optional, defaults to 12): ViT encoder depth.
• vision_hidden_dim (int, optional, defaults to 768): ViT hidden dimension.
• vision_patch_size (int, optional, defaults to 32): ViT patch size.
• vision_mlp_ratio (float, optional, defaults to 4.0): MLP expansion ratio.
• hidden_act (str, optional, defaults to "quick_gelu"): MLP activation.
• layer_norm_eps (float, optional, defaults to 1e-5): LayerNorm epsilon.
• input_tensor (tensor, optional): pre-existing input tensor.
• name (str, optional, defaults to "CLIPVisionModel"): model name.

Returns a dict:

• last_hidden_state ((B, num_patches + 1, vision_hidden_dim)): per-token features, CLS first.
• pooler_output ((B, vision_hidden_dim)): the post-LayerNorm CLS token.

CLIPTextModel

CLIPTextModel(max_seq_len=77, vocab_size=49408, text_hidden_dim=512, text_num_heads=8,
              text_num_layers=12, text_mlp_ratio=4.0, hidden_act="quick_gelu",
              layer_norm_eps=1e-5, input_tensor=None, name="CLIPTextModel")

The text tower on its own: token and positional embedding, a causal-masked transformer stack, the post-encoder LayerNorm, and the EOT-position pluck. No vision tower and no text_projection.

Parameters

• max_seq_len (int, optional, defaults to 77): text input length.
• vocab_size (int, optional, defaults to 49408): tokenizer vocabulary size.
• text_hidden_dim (int, optional, defaults to 512): text encoder hidden dimension.
• text_num_heads (int, optional, defaults to 8): text encoder attention heads.
• text_num_layers (int, optional, defaults to 12): text encoder depth.
• text_mlp_ratio (float, optional, defaults to 4.0): MLP expansion ratio.
• hidden_act (str, optional, defaults to "quick_gelu"): MLP activation.
• layer_norm_eps (float, optional, defaults to 1e-5): LayerNorm epsilon.
• input_tensor (dict, optional): pre-existing inputs, keyed "token_ids" and "padding_mask".
• name (str, optional, defaults to "CLIPTextModel"): model name.

Returns a dict:

• last_hidden_state ((B, max_seq_len, text_hidden_dim)): per-token features.
• pooler_output ((B, text_hidden_dim)): the feature at the EOT position.

CLIPImageEmbed

CLIPImageEmbed(embed_dim=512, image_size=224, vision_num_layers=12,
               vision_hidden_dim=768, vision_patch_size=32, vision_mlp_ratio=4.0,
               hidden_act="quick_gelu", layer_norm_eps=1e-5, input_tensor=None,
               name="CLIPImageEmbed")

CLIPVisionModel plus the bias-free visual_projection, producing the same image side as CLIPModel without instantiating the text tower or logit_scale.

Parameters are those of CLIPVisionModel, plus:

• embed_dim (int, optional, defaults to 512): shared joint embedding dimension.

Returns a dict:

• image_embeds ((B, embed_dim)): projected image embeddings.
• last_hidden_state ((B, num_patches + 1, vision_hidden_dim)): pre-projection features.

CLIPTextEmbed

CLIPTextEmbed(embed_dim=512, max_seq_len=77, vocab_size=49408, text_hidden_dim=512,
              text_num_heads=8, text_num_layers=12, text_mlp_ratio=4.0,
              hidden_act="quick_gelu", layer_norm_eps=1e-5, input_tensor=None,
              name="CLIPTextEmbed")

CLIPTextModel plus the bias-free text_projection, producing the same text side as CLIPModel.

Parameters are those of CLIPTextModel, plus:

• embed_dim (int, optional, defaults to 512): shared joint embedding dimension.

Returns a dict:

• text_embeds ((B, embed_dim)): projected text embeddings.
• last_hidden_state ((B, max_seq_len, text_hidden_dim)): pre-projection features.

Key names differ from CLIPModel. These two return image_embeds / text_embeds, while CLIPModel returns image_embeddings / text_embeddings.

Preprocessing

CLIPImageProcessor

CLIPImageProcessor(image_resolution=224, mean=(0.48145466, 0.4578275, 0.40821073),
                   std=(0.26862954, 0.26130258, 0.27577711), do_center_crop=True,
                   do_normalize=True, do_resize=True, data_format=None)

Resizes the shortest edge to image_resolution with PIL bicubic, center-crops to a square, rescales to [0, 1], and normalizes.

Parameters

• image_resolution (int, optional, defaults to 224): target square resolution.
• mean (tuple, optional, defaults to the OpenAI CLIP mean): per-channel normalization mean.
• std (tuple, optional, defaults to the OpenAI CLIP std): per-channel normalization std.
• do_center_crop (bool, optional, defaults to True): center-crop after the resize.
• do_normalize (bool, optional, defaults to True): apply mean/std normalization.
• do_resize (bool, optional, defaults to True): resize before cropping.
• data_format (str, optional): "channels_last" or "channels_first". Defaults to keras.config.image_data_format().

Call processor(image), where image is a path, a list of paths, a PIL image, or an array. Returns a dict:

• pixel_values ((B, H, W, 3)): preprocessed images, in the configured data format.

CLIPTokenizer

CLIPTokenizer(variant=None, tokenizer_file=None, max_seq_len=77,
              unk_token="<|endoftext|>", bos_token="<|startoftext|>",
              eos_token="<|endoftext|>", pad_token="<|endoftext|>")

Byte-level BPE on the tokenizers Rust backend. Loads the variant's tokenizer.json from the clip release tag and applies CLIP's truncation and <|endoftext|> padding.

Parameters

• variant (str, optional): CLIP variant key. Defaults to "clip_vit_base_16".
• tokenizer_file (str, optional): explicit tokenizer.json path, overriding variant.
• max_seq_len (int, optional, defaults to 77): padded and truncated length.
• unk_token / bos_token / eos_token / pad_token (str, optional): special token strings.

Call tokenizer(inputs) with a string or list of strings. Returns a dict:

• input_ids ((B, max_seq_len)): token ids.
• attention_mask ((B, max_seq_len)): 1 for real tokens, 0 for padding.

CLIPProcessor

CLIPProcessor(image_resolution=224, mean=..., std=..., do_center_crop=True,
              do_normalize=True, do_resize=True, variant=None, tokenizer_file=None,
              max_seq_len=77, unk_token="<|endoftext|>", bos_token="<|startoftext|>",
              eos_token="<|endoftext|>", pad_token="<|endoftext|>", tokenizer=None,
              image_processor=None)

A CLIPImageProcessor and a CLIPTokenizer behind one callable. Takes the union of both constructors' arguments, plus:

• tokenizer (CLIPTokenizer, optional): a pre-built tokenizer, instead of building one.
• image_processor (CLIPImageProcessor, optional): a pre-built image processor.

Call processor(text=None, images=None, image_paths=None). Returns a dict:

• input_ids ((B_txt, max_seq_len)): token ids.
• attention_mask ((B_txt, max_seq_len)): padding mask.
• images ((B_img, H, W, 3)): preprocessed images.

The model input keys differ from these, so remap when calling: input_ids becomes token_ids and attention_mask becomes padding_mask, as the examples below do.

Model Variants

Variant ids for CLIPModel.from_weights:

Variant id	Params	Patch	Resolution	Source
clip_vit_base_16	~150 M	16	224	openai
clip_vit_base_32	~151 M	32	224	openai
clip_vit_large_14	~428 M	14	224	openai
clip_vit_large_14_336	~428 M	14	336	openai
clip_vit_g_14	~1.4 B	14	224	laion2b s12B b42K
clip_vit_bigg_14	~2.5 B	14	224	laion2b 39B b160k

Basic Usage: Zero-Shot Classification

import keras
from kerasformers.models.clip import CLIPProcessor, CLIPZeroShotClassify

processor = CLIPProcessor.from_weights("clip_vit_base_16")
model = CLIPZeroShotClassify.from_weights("clip_vit_base_16")

labels = [
    "a photo of two cats",
    "a photo of a bear",
    "a photo of a skier",
    "a photo of green apples",
]
inputs = processor(text=labels, image_paths="assets/data/coco_cats.jpg")
output = model({
    "images": inputs["images"],
    "token_ids": inputs["input_ids"],
    "padding_mask": inputs["attention_mask"],
})

# (1, 4): one image, four class prompts. Softmax over the text axis.
probs = keras.ops.convert_to_numpy(
    keras.ops.softmax(output["image_logits"], axis=-1)
).squeeze()
for label, p in zip(labels, probs):
    print(f"{p:.6f}  {label}")

0.999611  a photo of two cats
0.000001  a photo of a bear
0.000003  a photo of a skier
0.000386  a photo of green apples

Use CLIPZeroShotClassify, not CLIPModel: the latter returns image_embeddings / text_embeddings and has no image_logits key.

Batch Processing Multiple Images

Pass a list of images. image_logits becomes (num_images, num_texts), one row per image, and the same label set is scored against each:

import keras
from kerasformers.models.clip import CLIPProcessor, CLIPZeroShotClassify

processor = CLIPProcessor.from_weights("clip_vit_base_16")
model = CLIPZeroShotClassify.from_weights("clip_vit_base_16")

image_paths = ["assets/data/coco_cats.jpg", "assets/data/coco_bear.jpg"]
labels = [
    "a photo of two cats",
    "a photo of a bear",
    "a photo of a skier",
    "a photo of green apples",
]

inputs = processor(text=labels, image_paths=image_paths)
output = model({
    "images": inputs["images"],
    "token_ids": inputs["input_ids"],
    "padding_mask": inputs["attention_mask"],
})

probs = keras.ops.convert_to_numpy(
    keras.ops.softmax(output["image_logits"], axis=-1)
)                                        # (2, 4)
for path, row in zip(image_paths, probs):
    print(f"\n{path}")
    for label, p in zip(labels, row):
        print(f"  {p:.6f}  {label}")

assets/data/coco_cats.jpg
  0.999611  a photo of two cats
  0.000001  a photo of a bear
  0.000003  a photo of a skier
  0.000386  a photo of green apples

assets/data/coco_bear.jpg
  0.000001  a photo of two cats
  0.999802  a photo of a bear
  0.000192  a photo of a skier
  0.000004  a photo of green apples

Supervised Image Classification: CLIPImageClassify

Mirrors HF's CLIPForImageClassification: the CLIP vision encoder feeds a mean-pool over the patch tokens (CLS excluded) and a single linear classifier Dense producing num_classes logits. The text tower, visual projection, and logit_scale are not built.

The classifier head is a plain Dense, so this class is only meaningful with a checkpoint whose head was actually trained. None of the release variants in the table above carry one: they are all base CLIP, so CLIPImageClassify.from_weights("clip_vit_base_16") leaves the head randomly initialized and its predictions are meaningless. Point it at a fine-tune, or train the head yourself.

import keras
from kerasformers.models.clip import CLIPImageClassify, CLIPImageProcessor

# A checkpoint whose classifier head was trained
model = CLIPImageClassify.from_weights("hf:<user>/clip-finetuned-imagenet")
image_processor = CLIPImageProcessor()

inputs = image_processor("cat.jpg")          # {"pixel_values": (1, 224, 224, 3)}
logits = model(inputs["pixel_values"])       # (B, num_classes)
pred = keras.ops.argmax(logits, axis=-1)

The processor returns a dict, so index ["pixel_values"] before calling the model rather than passing the dict straight in.

Construct from scratch for fine-tuning on a new dataset:

model = CLIPImageClassify(
    num_classes=10,                  # your class count
    image_size=224,
    vision_num_layers=12,
    vision_hidden_dim=768,
    vision_patch_size=16,
    vision_mlp_ratio=4.0,
    hidden_act="quick_gelu",         # or "gelu" / "gelu_new"
    layer_norm_eps=1e-5,
)
model.output_shape                   # (None, 10)

Mind the argument names. Keras forwards unrecognized keywords up to Model, so a typo like num_labels=10 or vision_width=768 is swallowed silently and you get a model built from the defaults (num_classes=1000) with no error raised.

You can also warm-start the vision encoder from a CLIPModel checkpoint (the encoder weight names match across both classes):

src = CLIPModel.from_weights("clip_vit_base_16")
ac = CLIPImageClassify(
    num_classes=10, image_size=224, vision_num_layers=12,
    vision_hidden_dim=768, vision_patch_size=16, vision_mlp_ratio=4.0,
)
# Transfer the vision encoder weights; leave the classifier random
for src_layer, dst_layer in zip(src.layers, ac.layers):
    if "vision_model" in dst_layer.name and src_layer.name == dst_layer.name:
        dst_layer.set_weights(src_layer.get_weights())

Data Format

Both the models and the processors support channels_last and channels_first. Neither is hard-coded to a layout, so the whole pipeline runs either way.

They pick the format differently, which is the one thing to keep straight:

	How it picks the format
Processors	A data_format kwarg, per instance. None (the default) resolves to keras.config.image_data_format().
Models	Read keras.config.image_data_format() when they are constructed. There is no data_format argument.

So a processor can be overridden on its own, while a model follows the global setting in force at build time.

Overriding the processor only

CLIPImageProcessor(data_format="channels_last")("photo.jpg")
# {"pixel_values": (1, 224, 224, 3)}

CLIPImageProcessor(data_format="channels_first")("photo.jpg")
# {"pixel_values": (1, 3, 224, 224)}

Switching the whole pipeline

Set the global format before constructing the model, and both sides agree:

import keras

keras.config.set_image_data_format("channels_first")

processor = CLIPProcessor.from_weights("clip_vit_base_16")
model = CLIPZeroShotClassify.from_weights("clip_vit_base_16")

inputs = processor(text=labels, image_paths="assets/data/coco_cats.jpg")
# inputs["images"] is (1, 3, 224, 224)
output = model({
    "images": inputs["images"],
    "token_ids": inputs["input_ids"],
    "padding_mask": inputs["attention_mask"],
})

The probabilities are the same under either layout. Only the tensor shape changes.

Note that keras.config.set_image_data_format is global state. Set it once at the top of a script rather than toggling it between calls, since already-built models keep the layout they were constructed with.

Loading Fine-tuned and Community Weights

You are not limited to the official variants above. Any Hugging Face repo whose model_type is "clip" loads directly with the hf: prefix: the original OpenAI checkpoints, LAION variants, and arbitrary user fine-tunes.

from kerasformers.models.clip import CLIPZeroShotClassify

# The original OpenAI checkpoints
model = CLIPZeroShotClassify.from_weights("hf:openai/clip-vit-base-patch16")

# A LAION variant, which uses "gelu" rather than "quick_gelu"
model = CLIPZeroShotClassify.from_weights("hf:laion/CLIP-ViT-B-16-laion2B-s34B-b88K")

# Somebody's fine-tune
model = CLIPZeroShotClassify.from_weights("hf:<user>/clip-finetuned-on-my-data")

No shape arguments are needed. The architecture is read from the repo's config.json and mapped onto the constructor. That includes hidden_act, which matters in practice: OpenAI checkpoints set it to "quick_gelu" while LAION ones use "gelu", and reading it from the config is what keeps both bit-close to their reference.

All seven model classes accept hf:, as do CLIPProcessor, CLIPImageProcessor, and CLIPTokenizer, so you can pull the matching preprocessing from the same repo:

processor = CLIPProcessor.from_weights("hf:openai/clip-vit-base-patch16")

Loading hf:openai/clip-vit-base-patch16 and the clip_vit_base_16 release variant produces identical outputs, since they are the same checkpoint by two routes.
